Zoom H5 4-Track Portable Recorder

Zoom H5 4-Track Portable Recorder featured with Four tracks of simultaneous recording and interchangeable mic capsules make the H5 flexible and powerful enough to meet the evolving needs of today’s creators. This Zoom H5 4-Track Portable Recorder is Ideal for documentaries, podcasting, audio for video, and professional sound design, the Zoom H5 portable handheld recorder lets you quickly record up to four input signals regardless of your audio experience. The design of the XYH-5 mic capsule allows the H5 to handle up to 140 dB SPL equivalent to the sound of a jet aircraft from less than 200 feet away. And to keep your levels under control, the H5 offers compression and limiting. The Zoom H5’s rubberized housing and shock-mounted microphones minimize vibration and handling noise, while a low-cut filter helps eliminate wind noise and other kinds of low-frequency rumble. It utilizes the same high-quality, low-noise preamps as our flagship H6, ensuring great-sounding recordings in all sonic environments. In this Zoom H5 4-Track Portable Recorder, XLR/TRS combo inputs can handle both mic- and line-level signals for microphones, wireless receivers, mixers, keyboards and more. Each input has a dedicated gain control knob. The supplied XYH-5 capsule also provides an additional mic/ line input via a â…›” mini phone jack. This Four-track simultaneous recording and also Records directly to SD and SDHC cards up to 32 GB Up to 24-bit/96 kHz audio in BWF-compliant WAV or a variety of MP3 formats. Two mic/line inputs with XLR/TRS combo connectors, each with selectable phantom power and -20 dB pad. Here, Built-in effects, including low-cut filtering, compression, and limiting, Auto-record, Pre-record, and Backup-record functions mean that you’ll never miss that perfect take Multichannel and stereo USB audio interface for PC/ Mac/ iPad with LoopBack function, Powered by two AA batteries or via USB, Over 15 hours of operation with alkaline batteries.

General:

This Portable Recorder featured with SD card: 16MB to 2GB, SDHC card: 4GB to 32GB, and Backlit LCD (128 x 64 pixels)

Inputs:

Here, input portion featured with 400mw 8 Ω mono built in speMic type: Unidirectional, Sensitivity: -45 dB, 1 kHz at 1 Pa, Input gain: -∞ to 52 dB, Max sound pressure input: 140 dB SPL. Connector: 1/8″ stereo mini jack, Output Level: 20 mW +20 mW into 32 Ω load for Phone Output.

Recording Formats:

Here, Recording Formats featured with WAV (BWF-compliant), Sampling frequency: 44.1/48/96 kHz, Bit rate: 16/24 (Stereo), Maximum simultaneous recording tracks: 2, MP3, Sampling frequency: 44.1kHzBit rate: 48/ 56 /64 / 80/ 96/ 112/ 32/ 160/ 192/ 224/ 256/ 320 kbps, WAV (BWF-compliant)Sampling frequency: 44.1/48 kHz, Bit rate: 16/24 (Mono/Stereo) & Maximum simultaneous recording tracks: 6 (L/R + INPUT 1/2 + L/R backup).

USB:

Here, USB 2.0 High Speed, Sampling frequency: 44.1/48kHz, Bit rate: 16/24 bit, Inputs / Outputs: 4 / 2, Class: USB 2.0 Full Speed, Sampling frequency: 44.1/48kHz, Bit rate: 16 bit, Inputs / Outputs: 2 / 2, USB bus powered operation possible (iPad operation supported in Stereo mode only) are available.

Power Requirements:

In this AA size (LR6) battery x 2, AC adapter: AD-17 (DC5V/1A/USB-type) (optional) & USB bus power are included.

This latest Zoom H5 4-Track Portable Recorder has no warranty.
